Technical information
Générales
-Smoke outlet : Ø 250 mm
-Weight : 230 kg version de base
-Size logs : 80 cm
-In compliance with : EN 13229
-Size : 91 cm
Régulation manuelle
-Nominal output : 12,3 kW
-Maximum output : 24 kW (indicatif)
-CO Rate : 0,08%
-Particles emission (mg/Nm3) : 32 mg/Nm3
-Efficiency : 73,9%
- Damper: with adjustable sealing - Swing-door: the door is blocked when the damper is closed - Lift door : the damper automatically opens at the door opening.
Options : - Lift door - Convector - black screen printed glass door - Brass or stainless steel decoration around the door - Adapter for double combustion connection Ref : A0210
