Surface-mount electrical enclosure Resi9

recessedhomeempty

This Resi9 CX enclosure is a surface mounted distribution enclosure. This plastic enclosure is composed of 1 row of 13 modules of 18 mm. It can accomodate all types of modular switchgear. This enclosure is dedicated to indoor installation. The IP degree of protection is IP30 without door and IP40 with door. An optional door can be installed over the cover. The colour of enclosure is white (RAL 9003). It is intended for new or renovated installation in residential. The cables can enter via the 4 sides or via the back of the enclosure. It is equipped with an optional back plate and a front cover with notch. It is provided with removable DIN rail. It is provided with earth terminal block with its support. The terminal block has 14 outgoers (3x25mm²+11x4mm²). Marking label and label protector, blanking plate are also delivered within the product. The dissipated power is 27W. The In rated current is up to 63A. This product complies with IEC 61439-1 and 3, IEC60670-1 and 24 standard. The dimensions are (W) 252mm x (H) 250mm x (D) 108mm. According to EN/IEC 60695-2-11 standard, the fire resistance is self-extinguishing at 650°C. The operating temperature is -15°C to 60°C. The IK degree of protection is IK08. The operating temperature is -15°C to 60°C.
