10% greater excitation force than other products in the same category resulting in 16.7% greater production.
The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
The engine air filter is raised and the air is filtered twice to protect the engine.
The hydraulic system contains three stage filtration.
Cab mounted on vibration damping mounts
Cab temperature control
Operator control forces have been reduced
Rounded bumpers front and rear
Large rear glass and sloped hood for greater visibility
Weight at Drum 5000kg
Weight at Rear Axle 5000kg
Vibration Frequency 30/30Hz
Nominal Amplitude 2.0/1.0mm
Centrifugal Force 246/124kN
Drum Width 246/124kN
Travel Speed 0~9 / 0~5.5km/h
Theoretical Gradeability Vibratory 40%
Engine Model DONGFENG CUMMINS 4BTAA3.9-C12
Rated Power 93kW
