Metal ceiling suspension system MAXISPAN T24 A,E™

tilefor entrywaysindoor

Up to 3 m span due to the strength of the profiles No need for hangers in the soffit The Rockfon System MaxiSpan T24 A,E – Click is a unique and cost-efficient installation system for corridors where the grid is suspended from the walls. This system comprises Chicago Metallic 8270 and wall bracket. The system is perfect for corridors and large, single spans typically up to 3m wide with heavily-serviced ceiling voids, providing more flexibility and freedom to install and maintain the services. It is ideal for use with a variety of tiles including wide planks to create a more seamless appearance than traditional grids, by using less grid components. The grid system can be combined in many different ways to suit a wide range of tile dimensions, e.g. with T24 click 2890. Main runners have a height of 75 mm providing higher stability. Load Bearing - - Rockfon® System Maxispan T24 A,E™ Click/Hook deflection Corrosion Resistance - Class B (EN13964) - Demountability - Tiles installed in Rockfon System MaxiSpan T24 A,E are fully demountable - Fire Resistance - Some Rockfon ceiling systems have been tested and classified in accordance with European norm EN 13501-2 and/or national norms. Please contact Rockfon
