Logistic Data
Article No.
22318037
Code
RJH-A 46W/240/C/XE/B22D
Product EAN
4008597180378
Customs tariff no.
85392192
Box quantitiy (pcs.)
20
EAN Box
4008597480379
Gross weight of box in kg
0.87
Length of box in m
0.29
Width of box in m
0.23
Height of box in m
0.11
ETIM class
EC000038
ETIM class name
High voltage halogen lamp
Product status
Phase Out
Electric Parameters
Lamp power
46 W
Rated wattage
46.0 W
Energy Consumption kWh/1000h
46
Power factor
1.00
Lamp voltage
240-240 V
Mains voltage
240 V
Lamp voltage
240-240 V
Lamp's nominal current
0.19 A
Nominal current (mA)
192 mA
Light Application Parameters
Luminous flux
700 lm
Luminous efficiency
15.22 lm/W
Colour temperature
2700 K
Colour rendering index Ra
100
Service Life
Average nominal lifespan
2000 h
No. switching cycles
50000
Specification
Diameter max.
55 mm
Diameter
55 mm
Length max.
96 mm
Total length
96 mm
Burning position
beliebig
Mercury content
0.0 mg
dimmable
ja
Lamp shape
Pear-shape
Finish
clear
Model
Clear
