PROCONNEXmove construction joint profile is a maintenance-free, hard-wearing, durable profile made of solid aluminium to cover construction joints.
The perfected profile construction permits PROCONNEXmove to absorb movement in three dimensions. The profile is therefore capable of adapting to the movements in the floor covering structure. Middle sections which slide into each other offer a maximum adjustment rage of 10 mm.
The typical areas of application in interior rooms comply with Load Groups I and III, as described in ZDB Bulletin "Ceramic flooring with high mechanical loads", although they are specified for compression forces of 2 to 6 N/mm².
Product advantages:
- PROCONNEXmove is easy to fit
- Made entirely of solid anodised aluminium
- The structured surface provides PROCONNEXmove with a high degree of slip protection
- Gap-free visible surfaces guarantee minimal cleaning effort and reduce the accumulation of contaminants.
- Protection from mechanical stress
Construction joint profile
Specially designed for joint openings up to 32 mm wide in the substrate
Material
Anodised aluminium matt
Surface/colours
Silver
Length of profile
2,50 m
Height of profile
10 mm
Item No.:
61619
