Wall-mounted display panel 9000 SERIES

indooradvertisingLED

Fill their imagination. Create seamless displays. With an L-Line Professional LED Display Wall, the possibilities are endless. The bezel-free design, wide viewing angle and breathtaking brightness ensure authoritative imaging. At any size. Picture/Display Brightness before calibration - 750 nits Brightness after calibration - 650 nits Colour temperature default - 6500±500 K Colour temperature adjust range - 4000~9500 K (by software) Viewing angle (horizontal) - 160 Viewing angle (vertical) - 160 Brightness Uniformity - >=97% Contrast ratio (typical) - >=3000:1 Calibration (brightness/colour) - Supported Refresh rate (Hz) - 1920~3840 Frame frequency (Hz) - 50 & 60 Aspect ratio - 16:9 Picture enhancement - Dynamic contrast enhancement Wide colour gamut display Placement - Landscape Usage - 24/7 hrs, Indoor Convenience Signal control loop through - RJ45 Ease of installation - Locking mechanism for cabinet Guide pins Light weight Power loop through - For 230 V environments: 8 cabinets or less, for 110 V environments: 4 cabinets or less Operating conditions Temperature range (operation) - -20~45 Temperature range (storage) - -20~50 Humidity range (operation)[RH] - 10~80% Humidity range (storage) [RH] - 10~85% Power Max Power consumption (W) - <=160 Consumption (Typical) - <=53 Input voltage - AC100~240 V (50 and 60 Hz) BTU Value m2 - 2624 BTU/m2 Miscellaneous Warranty - 2 years Regulatory approvals - RoHS EN61000-3-2 EN61000-3-3 IEC/UL60950 IEC/UL62368 IEC62471 EN55032 EMC Class B FCC SDOC, Part 15 EN55035
