OPTICAL
PMMA acrylic lens, efficiency ~90 %.
Luminous flux according to Bining : from 120 to 150 lumens to 500 mA.
Color Temperature: 2700 K to 5000 K.
Service Range : 70 % of nominal flux after 25 000 hours.
Color Rendering Index: CRI 90
ELECTRICAL
1.5W Power LED.
Constant supply voltage of 8 to 28V compatible with DIM PWM consistent on input line.
Electric transmission by magnetic contact.
Protection against reverse polarity and connection management.
Power consumption to 2.5W max., excluding supply.
Electrical Classification : Class III SELV device.
MECHANICAL
Weight : 25gr
Electronic circuit encased in a fire proof polycarbonate housing (dim : 35 x 20 x 9 mm).
Articulating base, patented magnetic ball joint.
Magnetically attached.
Operating temperature : -5° +40°
ROHS components.
Interior use only.
