IP67 floodlight IRIS67
LEDcommercialoutdoor

IP67 floodlight
IP67 floodlight
IP67 floodlight
IP67 floodlight
IP67 floodlight
IP67 floodlight
IP67 floodlight
IP67 floodlight
Add to favorites
Compare this product


Characteristics

Protection class
IP67
Light source
LED
Application
commercial
Interior/exterior use
outdoor
Beam type
spot
Other characteristics
adjustable
Height

79 mm, 136 mm, 150 mm, 188 mm
(3 in, 5 in, 6 in, 7 in)

Length

55 mm, 89 mm, 113 mm
(2 in, 4 in, 4 in)

Width

47 mm, 77 mm, 116 mm
(2 in, 3 in, 5 in)

Power

6 W, 13 W, 22 W, 30 W

Luminous flux

128 lm, 242 lm, 262 lm

Color temperature

2,700 K, 3,000 K, 4,000 K

Color rendering index (CRI)

80 unit

Description

Single emission projectors for outdoor application. The super warm LED light source with a elliptical light distribution is composed of 1 arrayled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 685 lm, with a 114.2 lm/W nominal luminous efficacy. The device body is made of die-cast aluminium en ab - 46100 and features a embossed white ral 9003 finish, processed by means of open pore anodizing + powder coating The device body is made of die-cast aluminium en ab - 46100 and features a embossed white ral 9003 finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered; the diffuser is made of extra clear glass - tempered. The ingress protection degree is IP67; the total weight is of 0.210 kg. The power supply driver is not provided and is to be ordered separately. The total absorbed power is 6 W. The power supply cable is included and features a 1 m lenght. The device features protection class III and can be wall lights, ceiling or floor-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
