Surface mounted light fixture DUBLIGHT_SQ

LEDsquareIP40

A minimal shaped ceiling light with a minimal and contemporary design. Diffuser in satin-finished PMMA, mounting frame in white wrinkle-effect coated metal outlining either a square shape, in three different sizes, or rectangular, where a LED source is inserted. The light comes out of small regular openings that emphasise each other in an attractive pattern, for diffused lighting. Dublight_S can be placed in passageways, such as large corridors, workplace hallways, etc. Single emission ceiling lights for indoor application. The warm white LED light source with a general lighting light distribution is composed of 1 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 808 lm, with a 134.7 lm/W nominal luminous efficacy. The diffuser is made of pmma with a satin finishing treatment; the mounting frame is made of iron, with a embossed white ral 9003 finish, processed by means of coating. The ingress protection degree is IP40; the total weight is of 0.800 kg. The total absorbed power is 6 W. The device features protection class I and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
