Length (L) and distance of cantilever (A) as required (length of profile max. 6 m, longer profiles possible with adapter).
The light bar is rotatable, which enables orientation of the light beam.
Types
Vario 1: with cantilever for wall- and ceiling mounting
Vario 2: with cantilever and adjusting rings (light bar rotatable) for wall and ceiling mounting
Vario 3: with rectangular cantilever (light bar rotatable) for wall and ceiling mounting
Vario 4: with cantilever-plate made of stainless steel with adjusting ring (light bar rotatable) for wall mounting
U-profile
Profiles: U42 | U48 | U60 (mm)
Stainless steel L304 (V2A) / L316 (V4A)
Surface glass bead blasted or polished
Powder coating in RAL- or DB-colours on request
Illuminant
LED-light bar (single- or double-row)
Luminous colour (2700 / 3000 / 4000 / 5000 K) or RGB
Luminous intensity and beam angle as required.
