Panel curtain wall AA®110

metal and glassdecorative

The AA®110 SSG system allows glazing of the curtain walling to be achieved without the use of conventional pressure plate and face caps. The system is finished with a flush silicone weatherproof seal. It has been further developed to accommodate up to +/- 5mm differential vertical movement between the façade and the supporting sub-structure. The AA®110 SSG is a variant of our flagship AA®110 65mm curtain wall system, which allows glazing of the curtain walling to be achieved without the use of conventional pressure plate and face caps, giving an aesthetically pleasing appearance with flush glazing to the exterior. The grid construction replicates the AA®110 mullion drained system, so carries the same ease of installation. The flush external appearance is provided by specially manufactured insulated glazing units constructed with the use of structural silicone sealant and contain an integrated channel profile around the perimeter of the glazing cavity. Toggle clips positioned on the mullions and transoms locate into the channel profile to provide the mechanical retention to secure the pane to the curtain wall. The glazing unit is deadload supported by the transom using a combination of setting blocks and glass supports, additionally the final aesthetics of the façade is enhanced by use of a flush seal between the glass units by means of a UV resistant weatherproofing silicone sealant.
