Zinc profile Purlins C

Cfor rooffor wall

The "Z"- and "C" (Zed and Cee) shaped sections of Kamaridis GlobalWire Group are accurately roll-formed via cold forming from high-strength zinc-alloy coated steel in order to provide an efficient, lightweight and cost efficient roofing, cladding and walling support system, for framed structures. (Purling and girt system). The "Z" and "C" shaped section structural elements are manufactured through cold forming procedure from zinc-alloy coated steel Zinc-hi-ten® which minimum yield stress is by 60% higher than the respective profiles formed through hot forming. This means that we can use sections of minimum thickness and weight, resulting in reduction of the time and the cost of the construction. They are classified as "thin gauge member" profiles and the study as well as the analysis concerning their application is conducted according to the provisions of the European standard EN 1993-1.3: "Eurocode 3: Design of steel structures. Part 1.3: General rules. Supplementary rules for coldformed thin gauge member and sheeting" Base Metal Thickness (BMT) 1,5mm - 2,0mm - 2,5mm - 3,0mm Steel Quality: S320 (according to AS 1397-93) with guaranteed minimum yield stress of 320 N/mm2. (For further details, consult the section regarding the technical characteristics of the sheeting). Installation The "C" shaped section of KAMARIDIS GLOBALWIRE GROUP OF COMPANIES feature two spaced-apart parallel flanges and are suitable for construction of single span multi-bay buildings, channels, window and door trimmers. "C" shaped sections are also effective as antianemia.
