Hydraulic car lift IP1-HMT V07
commercialhomefor high-rise buildings

Hydraulic car lift - IP1-HMT V07 - IdealPark - commercial / home / for high-rise buildings
Hydraulic car lift - IP1-HMT V07 - IdealPark - commercial / home / for high-rise buildings
Add to favorites
Compare this product

Characteristics

Operation
hydraulic
Use
commercial, home, for high-rise buildings
Options
outdoor, indoor
Load

2,700 kg
(5,952 lb)

Width

Min.: 230 cm
(90.55 in)

Max.: 270 cm
(106.3 in)

Depth

Min.: 500 cm
(196.85 in)

Max.: 560 cm
(220.47 in)

Description

The IdealPark car lift mod. IP1-HMT V07, with international certification, allows driver on board during its lifting and/or lowering procedures for the course of its 11.9 m maximum travel distance. The platform size can be customized up to 270x560cm and it only requires 80cm of pit height. The lifts are equipped with a PLC with a touch screen display that manages several safety devices for the user, ranging from protective photocell barriers that monitor the exact position of the car on the platform, to a system that controls cable tension. A UPS device allows the platform to be lowered and the car lift doors to open even in the event of a power outage and ensures that the driver can leave the platform. The lifts with driver on board can be equipped with a remote control to call the platform directly from the car. The system can be fitted with a telephone dialer that allows the driver to contact the rescue centre operating 24 hours a day in case of emergency. The standard lifts are fully galvanised and can be coated in Triplex in a wide range of colours to harmonise them with the surrounding environment. A wide range of possible finishes and an innovative design allow for the perfect integration of the system in the architecture of the building and ensure maximum safety and comfort to the user. The IP1-HMT V07 system is designed to be installed both indoors and outdoors.

VIDEO
