Video and call function
Video transmission and call, Security room call for visitors
Security function
Front door control, fire detection and easy security function through the passwords of household and registered RF CARD and NFC, Bluetooth recognition
[optional] Information supply function
By 4.3 type LCD/auto door open function of lobby/visitors video checking function/card access function (optional)
Specifications
Product Features
ABS, aluminum, PC
Angle of view
97˚
Appearance
231.6W x 271.6H x 18D(mm) Rain Cover is excluded
Video input
1Vp-p/75Ω, Composite Video
Installation method
Embedded type
Call method
8 wire common BUS method
Weight
Approximately 1.0kg
LCD
4.3 type TFT-LCD COLOR
Device interlocking
RS-485
Temperature
-10℃~40℃
Power used
DC 24V ± 7V
Operation
14 Key Touch Button method
Power Consumption
Under 5W during standby, Maximum 20W
Relative humidity
20%~70%(Related humidity)
House Unit
Support 160 House Units
Card Reader
None
