Light switch Cheriton Victorian

rockerrecessedchrome

Capturing all the charm and elegance of the Georgian and Victorian period. The plates are traditional cast brass with a choice of finishes. The range consists of two designs, Georgian and Victorian. • Two designs – Georgian and Victorian • Georgian available in two finishes • Victorian available in six finishes • Switch inserts to match the plate finish • Standard box-fix electrical accessories • Grid and EuroFix options also available (see separate GRID-IT and EuroFix sections for inserts.) Primary Range Cheriton Victorian Insert Type 1 gang 10AX 2 Way Rocker Insert Colour Antique Brass/Black EAN13 Barcode 5017504018634 Commodity Code 85363010 Luckins TSI 387387349 Dimensions(Nominal) Single: Height = 88.5mm Width = 88.5mm Depth = 7.5mm Weight 157 GR Switched Poles Single Current Rating 10AX Voltage 220/250V AC Maximum Load 10 Amp inductive Mains Frequency 50Hz IP Rating IP2XD Contact Gap Minimum 3mm Terminal Capacity 1 5x1mm² Terminal Capacity 2 4x1.5mm² Terminal Capacity 3 1x2.5mm² Terminal Capacity 4 1x4mm² Multi-strand Terminal Capacity 5 1x6mm² Earth Terminal Capacity 1 5x1mm² Earth Terminal Capacity 2 4x1.5mm² Earth Terminal Capacity 3 3x2.5mm² Earth Terminal Capacity 4 1x4mm² Multi-strand Earth Terminal Capacity 5 1x6mm² Product Class 1 Must be earthed Ambient Operating Temperature -5° to +40°C Recommended Location Internal Use Only Maximum Installation Altitude 2000m
