Stainless steel video intercom

residentialwall-mountedexterior

The perfect combination of stainless steel panel and glass panel, equipped with 7-inch HD display and capacitive touch screen. The straight and resolute exterior design is integrated with the building style. Intuitive, easy-to-use, personalized software design interface brings a unique user experience. Touch operation mode GUI can be modified by software Support video intercom between residents and visitors Support real-time monitoring Support connecting external analog camera Support tamper alarm Door status detection, and unlock state timeout alarm A variety of unlocking methods: ——By Indoor Monitor ——By Swiping IC card ——By user password ——By public password Customizable GUI Support display of resident list, which can be modified by configuration tool Two calling methods: ——Call by keypad ——Call by resident list Support visual IC card management Support for power supply for external door locks (12V 800mA) Working Voltage DC 24-32V（by two wire power supply） Working Current 400mA（30V） Static Current 90mA WorkingTemperature -25℃ ~ +55℃ Screen size 7 inch color TFT Max. Card Management 2000 pcs Max. Apartment Management 128 households Unlockable type normally open / normally closed Camera Type CMOS Camera View Angle 70°x 50° Camera Resolution 0.3MP Minimum illumination 0.1 l Fill-in Light Type white
