Technical specification
Duty
Residential
Diameter
200 mm
Cylinder Stroke
600 mm
Finish
Painted Steel or Brushed Stainless Steel
Rise Time
5 sec
Descent Time
7 sec
Key features
Suitable for residential applications, providing intelligent control, but preserving the aesthetic impact
Product design streamlined, configurable by selecting the desired installation accessories
Ease of transport, storage and installation, thanks to the weight and content of the product
Simplified maintenance (possible by one person)
Available in standard painted steel or stainless steel
5mm thick steel cylinder with cataphoresis treatment and painted
Painted steel is power coated RAL 7021 dark grey metallic
Hydraulic lock in high position (in case of power failure) with special release key
Product details
The J200 range comes in hydraulic, semi automatic and fixed versions
