Indoor kitchen drawer 3188112

Vertex Kit for kitchen and bathroom drawer with all the necessary elements for its assembly. It is the optimal solution for your kitchen, bathroom or wardrobe furniture with an elegant design in silver painted steel, anthracite gray and white finish. Each kit is made up of all the elements necessary for mounting an external drawer of 131 mm height, sized for a board thickness of 16 mm for the bottom and back of the drawer. Includes: two sides, one set of soft-close runners, one set of covers and drawer front hooks. The metal sides are made of steel with silver painted, anthracite gray and white painted finish and allow the drawer front to be adjusted ± 2mm vertically and ± 1mm ​​horizontally. The guides are total extraction with soft closing and allow a maximum load of 60 Kg for the drawer. You will only need the boards cut to the correct dimensions for the bottom, the back and the front of the drawer. • Kit of fittings needed to assemble an exterior drawer with a height of 131 mm and depth of 500 mm, apart from the front, back and bottom. • Sized for a board thickness of 16 mm for the bottom and back of the drawer. • Synchronized total extraction runners, with soft closing and load capacity of 60 kg. • It has a 3D front adjustment: vertical by means of an eccentric of ±2 mm, horizontal ±1 mm, inclination -1,5/+4 mm. • Made of white painted steel.
