The MyHOME_Up load control system manages the maximum power used, automatically disconnecting the less important appliances (which we decide as such) in the event of an overload through the actuators to avoid blackouts.
The system offers the following features:
Manages up to 63 loads;
The controllable power value can be set in the control unit and is between 1.5 and 18 kW;
It can disable or re-enable the disconnection priorities configured in the event of a blackout; according to the customer’s needs;
It allows to check the correct functioning of the loads by measuring the differential current absorbed by them.
Central unit for load management
Devices to measure the current absorbed by the electrical system by means of toroids and to manage the actuators to avoid a blackout.
Actuator with current sensor
Thanks to the integrated current sensor it measures the consumptions of the controlled load and disconnects it from the electrical mains to avoid a blackout.
Actuator
Actuator device to disconnect the load from the electrical mains to avoid a blackout. Available in the flush-mounting version to be associated to the socket or DIN modularity.
HOMETOUCH device for displaying and controlling loads.
The new HOMETOUCH can be integrated into the system, capable of displaying the status of the loads controlled by the control unit and forcing operation independently of the control unit itself.
The system configuration
The commissioning of the system and the definition of the functions with the actuator control association, is easily carried out by using the MyHOME_Up app and the MyHOME Server1 gateway connected to the BUS and the Internet.
