Drainage channel with grating RainDrain Brickslot B 125
side-slottedpolymer concretewith metal grate

Drainage channel with grating - RainDrain Brickslot B 125 - ACO Building Drainage - side-slotted / polymer concrete / with metal grate
Drainage channel with grating - RainDrain Brickslot B 125 - ACO Building Drainage - side-slotted / polymer concrete / with metal grate
Add to favorites
Compare this product

Characteristics

Configuration
with grating, side-slotted
Material
polymer concrete
*grid material
with metal grate
Applications
for parking lot, paving
Level of traffic
light traffic, for pedestrian area
Other characteristics
rainwater

Description

Discreet slot drainage channel for driveway applications Manufactured from Vienite, ACO’s high strength recycled polymer concrete, ACO RainDrain Brickslot B 125 is suitable for vehicle traffic up to Load Class B 125 The high quality ACO RainDrain Brickslot B 125 channels interlock, allowing for quick and easy installation. The channel comes complete with an offset slotted grating, ideal for block paving up to and including 60mm. A full range of accessories are available, designed to aid simple and fast installation. Features & Benefits Features Discreet 10mm inlet slot Manufactured from recycled material Channel shape anchors product into concrete surround UKCA and CE marked and fully certified to Load Class B 125 BS EN 1433:2002 Benefits Knock-out for connection to 110mm PVC-U pipe Channels interlock for quick and easy installation Ideal for use with block paving up to 60mm
