Drainage channel with grating HexDrain B 125
compositepolypropylenemetal grate

Drainage channel with grating - HexDrain B 125 - ACO Building Drainage - composite / polypropylene / metal grate
Drainage channel with grating - HexDrain B 125 - ACO Building Drainage - composite / polypropylene / metal grate
Add to favorites
Compare this product

Characteristics

Configuration
with grating
Material
composite, polypropylene
*grid material
metal grate
Applications
for public spaces
Color availability
black
Level of traffic
for pedestrian area
Other characteristics
rainwater

Description

Drainage channel for light duty applications Manufactured from recycled polypropylene, ACO HexDrain B 125 is suitable for vehicle traffic up to Load Class B 125 - Pedestrian precincts, light vehicles, private car parks and drives. ACO HexDrain B 125 comes complete with a corrosion resistant black composite Heelguard grating, ideal for pedestrian traffic. The ACO Drainlock grating has a bar-less locking device, allowing for quick and simple installation of gratings. Complete the system with ACO’s range of accessories, designed to aid simple and fast installation Features & Benefits Features Anti-shunt prevents grating movement once installed Heelguard grating with 8mm slots Cutting guide to create half metre channels ACO Drainlock grating - this bar-less locking device allows quick and simple installation of gratings Vertical knockout for connection to PVC-U pipe or sump via outlet connectors UKCA and CE marked and fully certified to Load Class B 125 BS EN 1433:2002 Benefits Male and female channel connections clip together for quick and easy installation 100mm overall channel depth Environmentally friendly product - manufactured from recycled polypropylene and 100% recyclable Recommended Applications Driveways Small Private Car Parks

VIDEO
